Product Highlights
*It is provided with CUMMINS engine which offers strong power and is
time-tested.
*LOVOL original independent cooling loop system for working oil ensures
that the hydraulic system of the whole machine always works in a stable
state.
*The heavy-duty design, suitable for mining operations, enables the
equipment to cope with complex working conditions.
*The specially-developed dual-pump confluence technology for crushing
conditions has greater crushing force and higher efficiency among
machines of the same kind.
Product Parameters
|
Item
|
Unit
|
Parameter
|
|
Rated Power
|
kW/rpm
|
298/2000
|
|
Bucket Capacity
|
m³
|
2.3 Rock bucket
|
|
Operating Weight
|
kg
|
47500
|
|
Engine Model
|
-
|
CUMMINS QSM11
|
|
Number of Cylinders
|
-
|
6
|
|
Max. Torque/Speed
|
N.m/rpm
|
1898/1400
|
|
Displacement
|
L
|
10.8
|
|
Bucket Digging Force
|
kN
|
290
|
|
Arm Digging Force
|
kN
|
235
|
|
Max. Traction Force
|
kN
|
382
|
|
Max. Walking Speed
|
km/h
|
4.6
|
|
Min. Walking Speed
|
km/h
|
2.9
|
|
Rotary Speed
|
r/min
|
7.8
|
|
Gradeability
|
。
|
35
|
|
Ground Pressure
|
KPa
|
80
|
|
Max. Main Pump Flow
|
L/min
|
760
|
|
Main Safety Valve Pressure
|
MPa
|
34.3
|
|
Fuel Tank
|
L
|
670
|
|
Hydraulic Tank
|
L
|
370
|
|
Engine Oil
|
L
|
38
|
