Product Highlights
*Adopt reinforced chassis with enhanced drive roller, track roller, track
idler, carrier roller, and track crawler which could composite the reliable
frames for machines.
*Standard equipped with 2.5m3 rock bucket, the diversify devices is also
acceptable to satisfy the different demand of customers.
*Specialized design to match the crushing application. If it is equipped with
different attachments, the operator can choose the relative patterns on the
screen, for example, bucket model, hammer model, ripper model etc. to
match the working applications perfectly.
Product Parameters
|
Item
|
Unit
|
Parameter
|
|
Rated Power
|
kW/rpm
|
298/2000
|
|
Bucket Capacity
|
m³
|
2.5 Rock bucket
|
|
Operating Weight
|
kg
|
49000
|
|
Engine Model
|
-
|
CUMMINS QSM11
|
|
Number of Cylinders
|
-
|
6
|
|
Max. Torque/Speed
|
N.m/rpm
|
1898/1400
|
|
Displacement
|
L
|
10.8
|
|
Bucket Digging Force
|
kN
|
310
|
|
Arm Digging Force
|
kN
|
260
|
|
Max. Traction Force
|
kN
|
382
|
|
Max. Walking Speed
|
km/h
|
4.6
|
|
Min. Walking Speed
|
km/h
|
2.9
|
|
Rotary Speed
|
r/min
|
7.8
|
|
Gradeability
|
。
|
35
|
|
Ground Pressure
|
KPa
|
83
|
|
Max. Main Pump Flow
|
L/min
|
760
|
|
Main Safety Valve Pressure
|
MPa
|
34.3
|
|
Fuel Tank
|
L
|
670
|
|
Hydraulic Tank
|
L
|
370
|
|
Engine Oil
|
L
|
38
|
