Product Highlights
*The key components adopt renowned brands, like ISUZU engine, Kawasaki main
pump, main valve and rotary motor which have high reliability and great performance.
*Reliable chassis which is specially designed for mining application, the stress points
have been enhanced to extend whole machine’s service time.
*Reinforced working devices with 1.65m3 rock bucket could provide strong digging
force for tough applications
Product Parameters
|
Item
|
Unit
|
Parameter
|
|
Rated Power
|
kW/rpm
|
212/2000
|
|
Bucket Capacity
|
m³
|
1.65 Rock bucket
|
|
Operating Weight
|
kg
|
35800
|
|
Engine Model
|
-
|
ISUZU 6HK1XKSC
|
|
Number of Cylinders
|
-
|
6
|
|
Max. Torque/Speed
|
N.m/rpm
|
1080/1500
|
|
Displacement
|
L
|
7.79
|
|
Bucket Digging Force
|
kN
|
218
|
|
Arm Digging Force
|
kN
|
169
|
|
Max. Traction Force
|
kN
|
289
|
|
Max. Walking Speed
|
km/h
|
5.4
|
|
Min. Walking Speed
|
km/h
|
3
|
|
Rotary Speed
|
r/min
|
7.8
|
|
Gradeability
|
。
|
35
|
|
Ground Pressure
|
KPa
|
69
|
|
Max. Main Pump Flow
|
L/min
|
640
|
|
Main Safety Valve Pressure
|
MPa
|
34.3
|
|
Fuel Tank
|
L
|
630
|
|
Hydraulic Tank
|
L
|
340
|
|
Engine Oil
|
L
|
38
|
