Highlights
*Specialized CUMMINS engine which is the top power enterprise in the industry
ensures the greatest power demand.
*The engine matches perfectly with the transmission system and the working
hydraulic system to ensure high working efficiency whenever and wherever
possible.
*The reinforced drive axle provides a strong load-bearing support for the operation
of the whole machine.
*A variety of working devices and attachments are available, making it easy for you
to complete a number of tasks.
Parameters
Item |
Unit |
Parameter |
Rated Power |
kW |
180 |
Operating Weight |
kg |
23680 |
Bucket Capacity |
m³ |
4.5 |
Engine Model |
- |
CUMMINS QSL9.3 |
Max. Breakout Force |
kN |
185 |
Rated Load |
kd |
7000 |
Max. Traction Force |
KN |
189 |
Max. Gradeability |
° |
29 |
Max. Dump Clearance |
mm |
3120 |
Dump Reach |
mm |
1300 |
Wheel Tread |
mm |
2280 |
Wheelbase |
mm |
3500 |
Overall Dimension(L×W×H) |
mm |
8810x3240x3380 |
Type |
- |
Fix&Variable hydraulic system |
Steering Angle Each Direction |
- |
38º±1º |
Min. Turning Radius |
mm |
7290 |
Working Pressure |
Mpa |
24 |
Boom Lifting Time |
s |
6.2 |
Total Cycle Time |
s |
10.6 |
Fuel Tank |
L |
330 |
Hydraulic Tank |
L |
175 |
Engine Oil |
L |
20L |
