Products Highlights
*The Hydraulic system adopts industry-leading automatic adaptive technology, the flow automatically matched bases on the various application which could improve the working efficiency.
*The performance matching is optimized, the operation efficiency of machine rises 10%
*Adopt Kawasaki genuine hydraulic components, they are worthy of the trust on quality and performance.
*Ergonomic design makes driving and control natural and comfortable.
Products Parameters
|
Item
|
Unit
|
Parameter
|
|
Rated Power
|
kW/rpm
|
113.2/2100
|
|
Bucket Capacity
|
m³
|
0.92
|
|
Operating Weight
|
kg
|
21800
|
|
Engine Model
|
-
|
ISUZU AA-6BG1TRP
|
|
Number of Cylinders
|
-
|
6
|
|
Max. Torque/Speed
|
N·m/rpm
|
550/1600
|
|
Displacement
|
L
|
6.494
|
|
Bucket Digging Force
|
kN
|
143
|
|
Arm Digging Force
|
kN
|
116
|
|
Max. Traction Force
|
kN
|
217
|
|
Max. Walking Speed
|
km/h
|
4.9
|
|
Min. Walking Speed
|
km/h
|
2.7
|
|
Rotary Speed
|
r/min
|
11
|
|
Gradeability
|
°
|
35
|
|
Ground Pressure
|
KPa
|
44.9
|
|
Max. Main Pump Flow
|
L/min
|
456
|
|
Main Safety Valve Pressure
|
MPa
|
34.3/37.3
|
|
Fuel Tank
|
L
|
385
|
|
Hydraulic Tank
|
L
|
220
|
|
Engine Oil
|
L
|
20
|
|
Max. Digging Radius
|
mm
|
9875
|
|
Max. Digging Depth
|
mm
|
6510
|
|
Max. Unloading Height
|
mm
|
7260
|
|
Max. Digging Height
|
mm
|
1190
|
