Highlights
*Equipped with YUCHAI Tire 2 engine which has strong power, low fuel consumption and guaranteed quality.
*Enhanced front and rear drive axle, improved stability and reliability.
*Articulated frame structure with small turning radius, single pump and full hydraulic load sensing steering system provide easy and flexible operation as well as quick and accurate steering response.
*Soundproof cotton is installed in the hood and cab to reduce the noise of the whole machine by 3 db.
*Enlarged cab space, fine seal, new shock absorber, all these provide a more comfortable operation circumstance.
Parameters
Item |
Unit |
Parameter |
Rated Power |
kW |
58 |
Operating Weight |
kg |
6430 |
Bucket Capacity |
m³ |
1 |
Engine Model |
- |
YC4D80-T20 |
Max. Breakout Force |
kN |
58 |
Rated Load |
kd |
1800 |
Max. Traction Force |
KN |
48 |
Max. Gradeability |
° |
30 |
Max. Dump Clearance |
mm |
2510 |
Dump Reach |
mm |
940 |
Wheel Tread |
mm |
1630 |
Wheelbase |
mm |
2260 |
Overall Dimension(L×W×H) |
mm |
5800×2140×2920 |
Type |
- |
Single pump flow diffluence, |
Steering Angle Each Direction |
- |
35º |
Min. Turning Radius |
mm |
5080 |
Working Pressure |
Mpa |
17.5 |
Boom Lifting Time |
s |
5 |
Total Cycle Time |
s |
9 |
Fuel Tank |
L |
120 |
Hydraulic Tank |
L |
80 |
Engine Oil |
L |
13L |
