Products Highlights
*Equipped with world famous brand WEICHAI WP4.6N engine,which can provide strong power when working with low fuel consumption.
*Equipped with Linde hydraulic system which has good cooperation between the main pump and main valve.
*Reliable electrical system, reinforced working device,high strength abrasion resistant material.
*Large spacious cab, ergonomic design, low noise and low vibration.
Products Parameters
|
Item
|
Unit
|
Parameter
|
|
Rated Power
|
kW/rpm
|
129/2200
|
|
Bucket Capacity
|
m³
|
0.96
|
|
Operating Weight
|
kg
|
21500
|
|
Engine Model
|
-
|
WEICHAI WP4.6N
|
|
Number of Cylinders
|
-
|
4
|
|
Max. Torque/Speed
|
N.m/rpm
|
805/1400
|
|
Displacement
|
L
|
4.580
|
|
Bucket Digging Force
|
kN
|
156
|
|
Arm Digging Force
|
kN
|
109
|
|
Max. Traction Force
|
kN
|
217
|
|
Max. Walking Speed
|
km/h
|
5.1
|
|
Min. Walking Speed
|
km/h
|
3.1
|
|
Rotary Speed
|
r/min
|
12
|
|
Gradeability
|
。
|
35
|
|
Ground Pressure
|
KPa
|
47.5
|
|
Max. Main Pump Flow
|
L/min
|
2x299
|
|
Main Safety Valve Pressure
|
MPa
|
34.3
|
|
Fuel Tank
|
L
|
385
|
|
Hydraulic Tank
|
L
|
220
|
|
Engine Oil
|
L
|
13
|
