Highlights
*With LOVOL special engine power curves, the power system is of excellent
acceleration performance and agile response performance.
*The high rated load capacity makes your investments worthwhile in both operation
efficiency and life cycle.
*The LOVOL patented multi-stage power system enables you to always save
energy while running the equipment.
*Under complex working conditions, the power is automatically distributed that
makes operating efficiency of equipment improve greatly
Parameters
Item |
Unit |
Parameter |
Rated Power |
kW |
178 |
Operating Weight |
kg |
20600 |
Bucket Capacity |
m³ |
4 |
Engine Model |
- |
WEICHAI WD10G240E21 |
Max. Breakout Force |
kN |
185 |
Rated Load |
kd |
6000 |
Max. Traction Force |
KN |
175 |
Max. Gradeability |
° |
29 |
Max. Dump Clearance |
mm |
3150 |
Dump Reach |
mm |
1310 |
Wheel Tread |
mm |
2250 |
Wheelbase |
mm |
3400 |
Overall Dimension(L×W×H) |
mm |
8530×3050×3400 |
Type |
- |
Fix&Variable hydraulic system |
Steering Angle Each Direction |
- |
38°±1º |
Min. Turning Radius |
mm |
7130 |
Working Pressure |
Mpa |
18 |
Boom Lifting Time |
s |
5.7 |
Total Cycle Time |
s |
11 |
Fuel Tank |
L |
364 |
Hydraulic Tank |
L |
150 |
Engine Oil |
L |
20L |
