Products Highlights
*ISUZU engine provides excellent performance in both torque and oil consumption.
*The center of gravity position of machine is scientific analyzed optimized to make
the machine more stable.
*Genuine core components lay a reliable foundation for machine.
*It is a piece of versatile equipment which can be widely used for foundation
excavation, land consolidation, material transfer and other purposes.
*It is a machine which could be widely used on foundation digging, land cleaning
up, materials moving so forth.
Products Parameters
|
Item
|
Unit
|
Parameter
|
|
Rated Power
|
kW/rpm
|
120/2000
|
|
Bucket Capacity
|
m³
|
0.7-0.96
|
|
Operating Weight
|
kg
|
21000
|
|
Engine Model
|
-
|
ISUZU 4HK1
|
|
Number of Cylinders
|
-
|
4
|
|
Max. Torque/Speed
|
N.m/rpm
|
657/1500
|
|
Displacement
|
L
|
5.193
|
|
Bucket Digging Force
|
kN
|
156
|
|
Arm Digging Force
|
kN
|
109
|
|
Max. Traction Force
|
kN
|
217
|
|
Max. Walking Speed
|
km/h
|
5.1
|
|
Min. Walking Speed
|
km/h
|
3.1
|
|
Rotary Speed
|
r/min
|
12
|
|
Gradeability
|
。
|
35
|
|
Ground Pressure
|
KPa
|
47.5
|
|
Max. Main Pump Flow
|
L/min
|
2x234
|
|
Main Safety Valve Pressure
|
MPa
|
37.3
|
|
Fuel Tank
|
L
|
385
|
|
Hydraulic Tank
|
L
|
220
|
|
Engine Oil
|
L
|
20
|
